SPC Panel Flipping Machine Laminating SPC To Wood 5KG/M2

Name: SPC Panel Flipping Machine Laminating SPC To Wood 5KGM2
Brand: LONGYU
Price: 8000.00 USD

Brand Name : LONGYU

Certification : ISO9001

MOQ : 1Set

Price : 8000.00-16000.00

Payment Terms : T/T

Supply Ability : 10sets/month

Delivery Time : 30-60 days

Core Mechanism : Panel Flipping & Alignment

Target Product : Multi-layer Composite Panels

Key Industry : Door & Decorative Panel Manufacturing

Equipment Focus : Alignment Accuracy & Throughput

Capacity : 5-8t/h,10 tons/h for wood chipper,12-15 tons/h,3.3 cbm,1-2t/h

Weight : 180/160KGS,350kg,4070t,7500kg,808kg

Type : Wood Chipper,216,Agro-Forestry Monitoring System,Log Splitter

Production capacity : 98%,8-15 m3/hour,7-11cbm/h,7-8T/H,800-1500kg/h

Contact Now

Flip Board Lamination Machine

Specifications:

Technical Parameter	Specification
Model Number	LY-10-1300
Main Application	Laminating SPC to wood, insulation boards, door cores
Applicable Board Width	1 - 1.3 m
Applicable Board Length	2 - 3 m
Applicable Board Thickness	1 - 3 mm (for each layer)
Standard Equipment Length	6.5 m (Customizable)
Lift Platform Load Capacity	2 tons (Customizable)
Flipping Mechanism Load	5 KG/m²
Productivity (for 3m board)	Up to 4 pieces per minute
Power Supply	380V 50Hz 3-Phase (Optional)
Air Source Requirement	0.6 - 0.8 MPa

SPC Panel Flipping Machine Laminating SPC To Wood 5KG/M2

Quick Detail:

1. Efficient Panel Flipping: Specialized machine for accurately flipping and laminating one panel onto another.

2. Versatile Bonding: Designed for composing SPC with wood, insulation boards, and door cores.

3. High Productivity: Achieves a rate of 4 pieces of 3-meter boards per minute.

4. Heavy-Duty Construction: Features a robust 2-ton lift platform and a 5KG/m² flipping capacity

5. Space-Saving Design: Compact 6.5-meter length (customizable) for efficient floor space utilization.

SPC Panel Flipping Machine Laminating SPC To Wood 5KG/M2

Applications:
Core equipment for manufacturing layered composite panels:

Ecological Door Production: Laminating SPC or HPL surfaces onto wooden or honeycomb door cores.

Decorative Wall/Ceiling Panels: Bonding wear-resistant SPC surfaces to substrate boards like MDF or calcium silicate board.

Furniture Component Production: Creating composite panels for cabinets, tables, and other fixtures.

SPC Panel Flipping Machine Laminating SPC To Wood 5KG/M2
